Jeep Wrangler JKU Dash Phone Mount Extension

0 downloads21 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

This is a ~180mm extension arm with a RAM style ball mount, designed to mount with the existing screw in the center dash storage tray. You will have to cut the ridge out of the center of the tray liner for the base to mount properly. You will need: (4) 6mm x 35mm carriage or hex head screws (4) four 6mm wing nuts I used a Steelie magnetic ball mount for the phone found here: https://www.amazon.com/Nite-Ize-Original-Steelie-Mount/dp/B00BAQKRHY/ref=sr_1_3?keywords=magnetic+ball+phone+mount+car&qid=1552431993&s=gateway&sr=8-3, but you can use pretty much any of this style magnetic phone mount. ** MAKE SURE YOU PRINT THIS WITH ABS or PETG!! PLA cannot withstand the temperatures that are likely to occur in the dash of a vehicle.
