Files (1)

Mazda_3_Shift_Knob.stl

STL

1.2 MB

Print guidance estimate

Uses saved filament metadata

Print cost & setup estimate

Setup guidance plus saved or slicer-confirmed filament, cost, and time. Model file size is never treated as printable volume.

1 model file

Recommended kit

50g

Based on 35% main infill across listed model files

Material cost

$1.20

Filament only at roughly $24/kg PETG / ASA

Print time

2.0h saved / 1.4h–2.4h estimate

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 35%	100% solid	Recommendation
Mazda_3_Shift_Knob.stl	Primary model	1.2 MB STL	40g $0.95	50g $1.20	95g $2.27	Print with a higher infill for the center thread/core to withstand shifting forces

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Interior

Mazda 3 Shift Knob

0 downloads264 views0 likes

Shared by

Michael Chen

Verified

Description

My shift knob in my 2007 Mazda 3 broke, so instead of just buying a new one I created my own simple one. The picture shown does not have the knob screwed on all the way, it does go all the way down to the boot. I was worried about printing this upright and using support, but it worked just great. I have since printed it upright without support so it is whatever you want to do with your specific printer. The thread on it is M10x1.25, so even though I did this for a Mazda 3 it should fit any shifter that has that thread on it. It was a little hard to twist on, but I prefer that to ensure it won't come off while driving. I printed mine with a higher infill than I usually do (35%vs10%), this is because of the force that will be put on the center thread/core while shifting. I wanted give it a little more robustness while driving. I hope at least one person finds this useful, it is my first upload to Thingiverse. Enjoy.
