Trim Pieces

W124 Shift Boot Bezel

0 downloads51 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

2 piece shift bezel for a Mercedes W124 automatic trim panel to attach to a manual shift boot. Print with supports. Trim boot to the rough size of the pocket, pierce holes to allow retention with the through pins, assemble and clamp together the two parts and use a soldering iron or similar heat source to melt the pins to the lower piece to attach the two pieces together tdesigned around a boot with leather that was around.025" thick,.
