Files (10)
Based on 25% main infill for the largest likely-needed model file
Filament only at roughly $24/kg PETG / ASA
Uses 70 mm/s, 0.2 mm layers; verify supports in slicer
| STL file | Role | Source size | PETG / ASA 20% | PETG / ASA 25% | 100% solid | Recommendation |
|---|---|---|---|---|---|---|
| 2015_STI_block_off_plate.stl | Accessory piece | 13.8 KB STL | 8g $0.20 | 9g $0.22 | 20g $0.47 | Small functional file: print slowly; consider 80–100% infill for durability. |
| 2015_STI_block_off_plate_Left.stl | Choose left variant | 12.9 KB STL | 8g $0.20 | 9g $0.22 | 20g $0.47 | Small functional file: print slowly; consider 80–100% infill for durability. |
| 2015_STI_block_off_plate_Right.stl | Choose right variant | 12.7 KB STL | 8g $0.20 | 9g $0.22 | 20g $0.47 | Small functional file: print slowly; consider 80–100% infill for durability. |
| Extra_back_tabs_for_split_versions.stl | Accessory piece | 1.3 KB STL | 8g $0.20 | 9g $0.22 | 20g $0.47 | Small functional file: print slowly; consider 80–100% infill for durability. |
| Left_switch_plate_with_bracing.stl | Choose left variant | 30.6 KB STL | 9g $0.22 | 10g $0.24 | 22g $0.52 | Use PETG / ASA, 4 walls, 25% infill. Pick the matching side before printing. |
| Left_Switch_plate_without_bracing.stl | Choose left variant | 27.5 KB STL | 9g $0.21 | 10g $0.23 | 21g $0.50 | Use PETG / ASA, 4 walls, 25% infill. Pick the matching side before printing. |
| Right_switch_plate_with_bracing.stl | Choose right variant | 29.5 KB STL | 9g $0.22 | 10g $0.23 | 21g $0.51 | Use PETG / ASA, 4 walls, 25% infill. Pick the matching side before printing. |
| Right_Switch_plate_without_bracing.stl | Choose right variant | 26.4 KB STL | 9g $0.21 | 10g $0.23 | 21g $0.50 | Use PETG / ASA, 4 walls, 25% infill. Pick the matching side before printing. |
| Switch_plate_with_bracing.stl | Printable file | 38.0 KB STL | 9g $0.23 | 10g $0.25 | 23g $0.54 | Use a brim or raft for improved adhesion |
| Switch_plate_without_bracing.stl | Printable file | 34.5 KB STL | 9g $0.22 | 10g $0.24 | 22g $0.53 | Use a brim or raft for improved adhesion |
Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.
2015+ Subaru WRX STI Switch panel
Shared by
3DPrintedCarPartDescription
I wanted a nice OEM looking way to mount switches in a non permanent way. As far as I know, this will fit 2015+ STI models only. I don't know if it will fit the WRX as the interior is a bit different (please let me know if that is incorrect). There are several versions ranging from a basic plate to cover the area below the radio, to ready to install with switch cutouts. There are split 2 piece versions of each different model for people with smaller printers. For the split version with the switch cutouts, the left side has the tabs to fuse the halves together with glue (see bottom for adhesive I use). The solid plate split model does not have the tabs so I have also included just the tabs in a separate file. They are not required, but make life easier when joining the parts. As far as mounting. you'll have to get creative. I just lined it up and hot glued the inner edges, but you could make mounting brackets. Sand and/or fill to make smooth for paint or vinyl (I used 400 grit to finish, and auto-body filler to smooth gap from 2 piece print) LINKS: Switches- https://www.amazon.com/gp/product/B01F55SXVC/ref=ppx_yo_dt_b_asin_title_o00_s00?ie=UTF8&psc=1 Adhesive- https://www.amazon.com/J-B-Weld-50133-Tan-1-Pack/dp/B009EU5ZNO/ref=sr_1_5?crid=37XNWIN55A71K&keywords=jb%2Bweld%2Bplastic%2Bbonder&qid=1572083173&sprefix=JB%2Bweld%2Bplas%2Caps%2C121&sr=8-5&th=1&psc=1 Vinyl wrap- https://www.amazon.com/gp/product/B01CF3ONIE/ref=ppx_yo_dt_b_asin_title_o06_s00?ie=UTF8&th=1
Compatible Cars
Originally published on thingiverse.com by Ryan Graf (TheRygr11) · License: CC BY
