Files (1)

Double_Din_v1.stl

STL

58.3 KB

Print guidance estimate

Estimated from part metadata

Print cost & setup estimate

Planning numbers for filament, cost, time, and setup. Treat them as estimates until you confirm the file in your slicer.

1 model file

Recommended kit

11g

Based on 25% main infill across listed model files

Material cost

$0.28

Filament only at roughly $24/kg PETG / ASA

Print time

20m–33m

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 25%	100% solid	Recommendation
Double_Din_v1.stl	Primary model	58.3 KB STL	11g $0.25	11g $0.28	25g $0.60	Ensure a strong adhesion to the print bed to prevent warping

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Dashboard

Mitsubishi Double Din Adapter

1 downloads67 views0 likes

Shared by

Alfred

Verified

Description

This is a frame adapter to retain the use of the factory dash face surrounding the MMCS radio found in many of the 2008-2016 era Mitsubishi vehicles.This one specifically was designed to fit inside a 2013 lancer around a double din Kenwood head unit but it should fit any double din head that is replacing a MMCS. I purchased an aftermarket dash kit and was not satisfied with neither the fit nor finish and decided to design and print this adapter to keep my factory dash face. So glad I did.
