Nissan X-trail T30 4x4 gearbox oil stick

0 downloads73 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

This is an oil stick for X-trail T30 4x4 gearbox (2.0 l petrol, QR20DE). The service manual says "measure with appropriate stick". I found it hard to first dip a stick and then measure it so I made this.The H-notch is at 168 mm deep and L is at 174 mm, as the manual states. This works only for 4x4 models! 2WD has a different filling hole. Usage instructions: - Remove the oil filling cap. It is a 10 mm hexagon screw - Push the dipstick as deep as it goes - Take it out and read the result.
