Raspberry Pi 7 inch display mount for NB Miata - image

Files (1)

NB-RaspberryPiPanel.stl

STL

182.5 KB

Print guidance estimate

Estimated from part metadata

Print cost & setup estimate

Planning numbers for filament, cost, time, and setup. Treat them as estimates until you confirm the file in your slicer.

1 model file

Recommended kit

16g

Based on 25% main infill across listed model files

Material cost

$0.39

Filament only at roughly $24/kg PETG / ASA

Print time

27m–46m

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 25%	100% solid	Recommendation
NB-RaspberryPiPanel.stl	Primary model	182.5 KB STL	15g $0.36	16g $0.39	35g $0.85	Ensure a secure fit around the radio surround to prevent movement during driving

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Phone Mounts

Raspberry Pi 7 inch display mount for NB Miata

0 downloads33 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

This model was built in TinkerCAD, it was my first project so it is by no means perfect, but it's good enough for my purposes. The mounting holes may not be in the right spot. I ended up not using them, and currently my RPI display is held in just with the pressure of the radio surround. It's held up to several autocross events with no movement. Should fit any 1999-2005 Mazda Miata. The Raspberry Pi 4 (3 should also fit) mounts to the official 7 inch touchscreen display. The display mounts to the mount. Test prints were done in PLA, but I would use PETG or ABS for a final print, as it will be more suited to the high temperatures it will see inside a vehicle.
