Sidefeed Injector Installation Tool

0 downloads41 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

Worried about breaking the top cap of your side feed injectors when reinstalling them? Then this tool is for you. The top plate that covers the solenoid is known to break when hammered on. This tool allows you to distributes the force onto the injector body when installing them in tight places (mainly Subaru applications). Designed for yellow Unisia Jecs sidefeeds used in Subaru Legacy, STI and FXT applications. Will work with OEM, Deatschwerks, or Witchhunter injectors.
