Files (5)

model3_vent_cover_left_fixed.stl

STL

115.0 KB

model3_vent_cover_long_end_cap_v2.stl

STL

114.8 KB

model3_vent_cover_long_middle_v2.stl

STL

71.1 KB

model3_vent_cover_middle.stl

STL

41.0 KB

model3_vent_cover_right.stl

STL

73.7 KB

Print guidance estimate

Slicer data required

Print cost & setup estimate

Setup guidance plus saved or slicer-confirmed filament, cost, and time. Model file size is never treated as printable volume.

5 model files

Typical selected file

Slice required

Choose the needed variant and slice it; source file size is not printable volume.

Material cost

Slice required

Use the slicer's filament total; STL/3MF byte size is not a cost input.

Print time

Slice required

Slice with the recommended material, infill, orientation, and supports.

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 35%	100% solid	Recommendation
model3_vent_cover_left_fixed.stl	Choose left variant	115.0 KB STL	Slice file	Slice file	Slice file	Use PETG / ASA, 4 walls, 35% infill. Pick the matching side before printing.
model3_vent_cover_long_end_cap_v2.stl	Cover / cap	114.8 KB STL	Slice file	Slice file	Slice file	Use PETG / ASA; check sealing faces and supports unlikely.
model3_vent_cover_long_middle_v2.stl	Cover / cap	71.1 KB STL	Slice file	Slice file	Slice file	Use PETG / ASA; check sealing faces and supports unlikely.
model3_vent_cover_middle.stl	Cover / cap	41.0 KB STL	Slice file	Slice file	Slice file	Use PETG / ASA; check sealing faces and supports unlikely.
model3_vent_cover_right.stl	Choose right variant	73.7 KB STL	Slice file	Slice file	Slice file	Use PETG / ASA, 4 walls, 35% infill. Pick the matching side before printing.

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Vents

Tesla Model 3 Vent Cover

0 downloads43 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

This is a vent cover for the Tesla Model 3. Since it is not possible to turn off the fan air flow between the driver and passenger independently, this vent cover allows you to effectively block the air flow for either the driver or passenger. The vent cover is made up of 5 parts: left end cap, right end cap, and three middle sections. I used 2-56 threaded rods to hold all the pieces together, then wrapped the cover with 3M brushed black vinyl. The cover can be pushed behind the center display when not being used (the vents are closed in that section). It has a slight friction fit so it shouldn't slide around. It can be slid to either the driver or passenger side, and it stops before the side mirror directional vent, also a friction fit to hold it in place. When the fan is on the higher settings (e.g. 7+), it may lift upward a little due to the air pressure, but it should still hold in place and block the air. Print all the parts vertical, if possible. no supports needed. I printed using ABS, 100% fill with raft. Other material and settings can be used, of course. Update: I've fixed the left piece (it was missing the tab), and added a "long" version, which is a single long middle piece (if you have a large format printer), and end cap (x2). The end caps can be attached using 2-56 screws.
