Files (1)
Slice the required model files; source file size is not printable volume.
Use the slicer's filament total; STL/3MF byte size is not a cost input.
Slice with the recommended material, infill, orientation, and supports.
| STL file | Role | Source size | PETG / ASA 20% | PETG / ASA 40% | 100% solid | Recommendation |
|---|---|---|---|---|---|---|
| Jack_Pad.stl | Primary model | 46.0 KB STL | Slice file | Slice file | Slice file | Use a non-magnetic nozzle, such as brass, to avoid magnet interference |
Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.
Tesla Model S/X Jack Pad with captured magnets
Shared by
3DPrintedCarPartDescription
This is a Tesla Model S & Model X jack pad. It has cavities for captured magnets, but they are not required. This is still usable without magnets in it. I used these magnets: N35 Strong Round Disc Ring Magnet Rare Earth Neodymium 20mm x 10mm You'll need 2 per jack pad. I recommend printing with 100% infill, as you'll need a lot of compression protection when jacking up a 5000lb car. I would not use PLA. PETG or ABS would be your best bet, probably acrylic as well. I haven't tried making a set of these out of TPU, but it might actually work very well... if anyone makes a TPU set, please let me know! You have to insert the magnets while it's printing after the cavity is printed, but before the 1st layer of the cavity starts... so either pause your printer at the proper layer or be quick like a bunny and drop them in the hole at the right time. Be sure you aren't using a steel or otherwise magnet type heat block or nozzle. You must be using a non-magnetic nozzle, such as a brass nozzle. I'm including the Inventor file if anyone wants to remix or modify this. Please share any modifications you make!
Compatible Cars
Originally published on thingiverse.com by (Naonak) · License: CC BY
