Files (1)

3VZE_AFM_Cap_-_beta_2.stl

STL

35.2 KB

Print guidance estimate

Estimated from part metadata

Print cost & setup estimate

Planning numbers for filament, cost, time, and setup. Treat them as estimates until you confirm the file in your slicer.

1 model file

Recommended kit

13g

Based on 40% main infill across listed model files

Material cost

$0.30

Filament only at roughly $24/kg ABS / ASA

Print time

21m–36m

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	ABS / ASA 20%	ABS / ASA 40%	100% solid	Recommendation
3VZE_AFM_Cap_-_beta_2.stl	Cover / cap	35.2 KB STL	9g $0.22	13g $0.30	22g $0.53	Use ABS / ASA; check sealing faces and supports unlikely.

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Mechanical/Functional

Toyota 3VZE AFM Cap

1 downloads83 views0 likes

Shared by

Alfred

Verified

Description

THIS IS STILL A WORK IN PROGRESS, BUT FOR NOW WORKS FINE ON MY MOTOR. I WILL ADD UPDATED FILES WHEN I FINALIZE THEM. This is a replacement cap for the AFM (Air-Flow Meter) on the Toyota 3VZE (3.0L 6-cyl) motor commonly used in 85-95 Toyota Pickups, T100s and 4Runners. If your stock cap has sagged and interfered with your AFM's sliding arm (like mine did), you can print this part and silicone it on top of the AFM instead of inside. I recommend printing this in something temperature resistant like ABS, but I did print it with Inland's Tough PLA and had only minimal sagging in the middle part. Print upside down on your bed, no supports are needed. More about how this came to be here: https://www.yotatech.com/forums/f116/3vze-idling-rough-rich-316442/#post52481984
