Volvo V40 phone mount for centre console

0 downloads46 views0 likes

Shared by

3DPrintedCarPart

Verified

Description

Was looking for a phone mount to go near the centre console but couldnt find anything for the V40 so I made my own. This is made with a Samsung S10 in mind and it was made slightly wide incase I wanted a case on the phone, also wanted to have access to the bottom to be able to charge it if needed. To bolt it to the car it uses the existing Torx screw that is there, there are then 2 M5x20 bolts and locknut nuts on it, I could have done it with just 1 bolt and nut but I wanted to make sure its super secure Printing I have used Gyroid and 20% infill to make it a little thicker. I printed it on a.8mm nozzle for time and will do some post work to make it smooth on the sides that are visible however if you use a smaller nozzle your lines wont be as defines. SCALING. The phone mount may come out way oversize, just scale it to 10% in Cura and it will be the correct size:).
