Files (1)
Based on 25% main infill across listed model files
Filament only at roughly $24/kg PETG / ASA
Uses 70 mm/s, 0.2 mm layers; verify supports in slicer
| STL file | Role | Source size | PETG / ASA 20% | PETG / ASA 25% | 100% solid | Recommendation |
|---|---|---|---|---|---|---|
| battery_disconnect_bracket.stl | Mount / bracket | 128.6 KB STL | 13g $0.32 | 14g $0.34 | 31g $0.76 | Ensure proper orientation for minimal supports |
Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.
Bracket for Battery Connector
Shared by
3DPrintedCarPartDescription
This Bracket is for mounting the Battery Disconnect Holder (https://www.thingiverse.com/thing:5180683) to the front chassis mount on my Jeep JK Wrangler. I used a #10-24 x 1/2" long Flat Head Screw, and blue thread locker, to fasten the bracket to the stock mounting bracket on the chassis near the front bumper. The Battery Disconnect Holder is mounted to this bracket using four #8-32 x 5/8" long Button Head Socket Cap Screws and four #8-32 NyLok nuts. (Other suitable machine screw hardware will work too.) The wiring is 8 AWG from a set of Jumper Cables. I filed two notches in the Battery Disconnect Holder to accommodate the lanyard of the cover for the battery terminals.
Compatible Cars
Originally published on thingiverse.com by Daryll Smith (dsmith1960) · License: CC BY
