Magnetic Double Din Stereo Cover for Buicks or Roll Your Own - image

Files (5)

buickSteeoCover.stp

STP

159.8 KB

stereoCover.stl

STL

90.1 KB

stereoCoverMount.stl

STL

63.6 KB

stereoCoverMountBacking.stl

STL

66.5 KB

stereoCoverWithLogo.stl

STL

4.8 MB

Print guidance estimate

Estimated from part metadata

Print cost & setup estimate

Planning numbers for filament, cost, time, and setup. Treat them as estimates until you confirm the file in your slicer.

5 model files

Typical selected file

60g

Based on 25% main infill for the largest likely-needed model file

Material cost

$1.44

Filament only at roughly $24/kg PETG / ASA

Print time

1.7h–2.9h

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 25%	100% solid	Recommendation
buickSteeoCover.stp	Cover / cap	159.8 KB STP	14g $0.34	15g $0.37	34g $0.81	Use PETG / ASA; check sealing faces and verify in slicer.
stereoCover.stl	Cover / cap	90.1 KB STL	12g $0.29	13g $0.31	28g $0.68	Use PETG / ASA; check sealing faces and verify in slicer.
stereoCoverMount.stl	Cover / cap	63.6 KB STL	11g $0.26	12g $0.28	26g $0.62	Use PETG / ASA; check sealing faces and verify in slicer.
stereoCoverMountBacking.stl	Cover / cap	66.5 KB STL	11g $0.26	12g $0.28	26g $0.62	Use PETG / ASA; check sealing faces and verify in slicer.
stereoCoverWithLogo.stl	Cover / cap	4.8 MB STL	55g $1.33	60g $1.44	132g $3.16	Use PETG / ASA; check sealing faces and verify in slicer.

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Dashboard

Magnetic Double Din Stereo Cover for Buicks or Roll Your Own

5 downloads1.4K views0 likes

Need this part printed?

Tell us what you need and we'll help you get it 3D printed. Takes a minute — no account needed and no payment is collected.

Request print / quote

Opens a quick request form. No order is placed and no payment is collected. Prefer email? Email us instead.

Shared by

Alfred

Verified

Description

Magnetic cover for double din stereos in Buicks. I used Meshmixer to add the Buick Logo to the cover design (see coverLogo.mix). There is only a 0.4mm layer of plastic covering the finished side of the 12x3mm magnets on the mounting plate (print finished-side-down), so be sure to glue the magnets in BEFORE you remove the finished print from the build-plate. The other magnets can be glued in after removal. I finished these pieces with black acrylic artist paint applied with a natural sponge and then added the wood veneer to the back of the face-plate using Elmer's ProBond glue. Final attachment to the dashboard using Scotch fasteners as shown. I had to create the second layer of backing to accommodate 2 magnets in each backing plate hole - if you only use one magnet, then you don't need to print the 'Backing' file. You can also use the file named stereoCover.stl as a starting point in MeshMixer or another mesh editor to add your own logo.
