Porsche Boxster 986 Removable Cupholders - image

Files (3)

Bstr_Bracket7.stl

STL

72.1 KB

Bstr_Cupholder3.stl

STL

385.1 KB

Covers.stl

STL

2.8 KB

Print guidance estimate

Estimated from part metadata

Print cost & setup estimate

Planning numbers for filament, cost, time, and setup. Treat them as estimates until you confirm the file in your slicer.

3 model files

Recommended kit

42g

Based on 25% main infill across listed model files

Material cost

$1.01

Filament only at roughly $24/kg PETG / ASA

Print time

1.2h–2.0h

Uses 70 mm/s, 0.2 mm layers; verify supports in slicer

STL file	Role	Source size	PETG / ASA 20%	PETG / ASA 25%	100% solid	Recommendation
Bstr_Bracket7.stl	Mount / bracket	72.1 KB STL	11g $0.27	12g $0.29	27g $0.64	Ensure proper orientation in the slicer for optimal printing and minimal supports
Bstr_Cupholder3.stl	Mount / bracket	385.1 KB STL	19g $0.46	21g $0.50	46g $1.10	Ensure proper orientation in the slicer for optimal printing and minimal supports
Covers.stl	Cover / cap	2.8 KB STL	8g $0.20	9g $0.22	20g $0.47	Small functional file: print slowly; consider 80–100% infill for durability.

Saved setup guidance is used for material, infill, support, and per-file recommendation text; editable numbers are planning estimates only.

Cup Holders

Porsche Boxster 986 Removable Cupholders

0 downloads106 views0 likes

Shared by

Alfred

Verified

Description

Removable cupholders for Porsche 986 Boxster. Bracket wedges in between Center dash and Upper Center Console as shown. Cupholders can be stored in armrest when not in use. Assembly Instructions: 1. Insert the shorter side of bottom supports (L-shaped pieces) fully into the slots on the cupholders. Use a small amount of epoxy to hold them in place. 2. Spread a small amount of epoxy into the two small trim pieces (covers) and fix them to the tops of the bracket arms for a more finished look (not pictured). Secure with painters tape until set. 3. Insert the tabs of the center bracket piece into the slots on the two end pieces. No glue should be needed, but is optional. 4. Wedge the bracket into the space in your dash with the curved sides of the arms facing down.
